Introduction

In last week's post, MQTT was used to subscribe to a topic published by another client. This was achieved in part using the mqtt abstractions in the ESP Rust esp_idf_svc crate. Using the same crate, we can leverage abstractions to publish MQTT topics as well. In this post, we're going to look at how to configure an ESP using Rust to publish a topic to an MQTT broker.

๐Ÿ“š Knowledge Pre-requisites

To understand the content of this post, you need the following:

  • Basic knowledge of coding in Rust.

  • Basic familiarity with WiFi & MQTT.

๐Ÿ’พ Software Setup

All the code presented in this post is available on the apollolabs ESP32C3 git repo. Note that if the code on the git repo is slightly different then it means that it was modified to enhance the code quality or accommodate any HAL/Rust updates.

Additionally, the full project (code and simulation) is available on Wokwi here.

๐Ÿ›  Hardware Setup

Materials

๐Ÿ‘จโ€๐ŸŽจ Software Design

Note: The code in this post is largely similar to last week's post. Also please refer to the same section of the prior post for additional background.

In this post, we are going to configure the ESP to publish a topic to an MQTT broker. The steps include the following:

  1. Configure and Connect to WiFi

  2. Configure MQTT

  3. Create Client Instance and Define Event Behaviour

  4. Wait for Broker Connection

  5. Publish a Topic

๐Ÿ‘จโ€๐Ÿ’ป Code Implementation

๐Ÿ“ฅ Crate Imports

In this implementation, the following crates are required:

  • The anyhow crate for error handling.

  • The esp_idf_hal crate to import the peripherals.

  • The esp_idf_svc crate to import the device services (wifi in particular).

  • The embedded_svc crate to import the needed wifi and mqtt::client service traits.

  • The std::thread and std::time for sleep behavior and time measurement.

use anyhow;
use embedded_svc::mqtt::client::Event;
use embedded_svc::mqtt::client::QoS;
use embedded_svc::wifi::{AuthMethod, ClientConfiguration, Configuration};
use esp_idf_hal::peripherals::Peripherals;
use esp_idf_svc::eventloop::EspSystemEventLoop;
use esp_idf_svc::mqtt::client::{EspMqttClient, MqttClientConfiguration};
use esp_idf_svc::nvs::EspDefaultNvsPartition;
use esp_idf_svc::wifi::{BlockingWifi, EspWifi};
use std::{thread::sleep, time::Duration};

๐ŸŽ› Initialization/Configuration Code

1๏ธโƒฃ Obtain a handle for the device peripherals: Similar to all past blog posts, in embedded Rust, as part of the singleton design pattern, we first have to take the device peripherals. This is done using the take() method. Here I create a device peripheral handler named peripherals as follows:

let peripherals = Peripherals::take().unwrap();

2๏ธโƒฃ Configure and Connect to WiFi: this involves the same steps that were done in the wifi post.

3๏ธโƒฃ Create the MQTT Configuration Handle: Within esp_idf_svc::mqtt::Client there exists an MqttClientConfiguration abstraction. This is the abstraction needed to configure MQTT. MqttClientConfiguration contains a default method allowing us to configure MQTT with a default configuration. Following that we create an mqtt_config handle as follows:

let mqtt_config = MqttClientConfiguration::default();

Note that if you were to use MQTT with a more advanced configuration, then this is the abstraction you need to update. This includes things like adding certificates for secure connections, defining client IDs, hostnames, and passwords among other things. Refer to the documentation for the full list of members.

That's it for Configuration!

๐Ÿ“ฑ Application Code

1๏ธโƒฃ Create Client Instance and Define Event Behaviour: Within the EspMqttClient abstraction, there is a new method that is used to create an instance of EspMqttClient. new has the following signature:

pub fn new(
    url: &str,
    conf: &MqttClientConfiguration<'_>,
    callback: impl for<'b> FnMut(&'b Result<Event<EspMqttMessage<'b>>, EspError>) + Send + 'a
) -> Result<Self, EspError>

Note there are three parameters a url, a MqttClientConfiguration configuration, and a callback. The url as would be expected is the url of the broker and conf is the configuration we created earlier. callback is a closure where we would need to define Event behavior. Meaning, every time there is a broker Event, we need to know what it is and react accordingly. Event is an enum with the following signature:

pub enum Event<M> {
    BeforeConnect,
    Connected(bool),
    Disconnected,
    Subscribed(MessageId),
    Unsubscribed(MessageId),
    Published(MessageId),
    Received(M),
    Deleted(MessageId),
}

We're not going to react to all of the events but rather only the ones we care about. Those would be Connected that conveys that we are connected to a broker, Suscribed which means we are successfully subscribed to a topic, and Recieved that conveys we received a message from the broker. Other than that, we can simply print the message event.

For this application, we are going to use the HiveMQ broker service. The service broker url is mqtt://broker.mqttdashboard.com . Before running this code, you would need to go to the HiveMQ page and click connect. While connected, on the same page, you can define a topic to publish and a message then click publish. This would publish the message for any subscriber to read.

Following all of the above, a client handle is created as follows:

let mut client = EspMqttClient::new(
    "mqtt://broker.mqttdashboard.com",
    &mqtt_config,
    move |message_event| {
        match message_event.as_ref().unwrap() {
            Event::Connected(state) => println!("Connected"),
            Event::Subscribed(id) => println!("Subscribed to {} id", id),
            Event::Received(msg) => {
                if msg.data() != [] {
                    println!("Recieved {}", std::str::from_utf8(msg.data()).unwrap())
                }
            }
            _ => println!("{:?}", message_event.as_ref().unwrap()),
        };
    },
)?;

Note how the match statement matches what we mentioned earlier. The only additional thing to mention here is how we are handling the received message. Recieve wraps a EspMqttMessage type. EspMqttMessage has several methods to process the incoming message. One of the methods is data that recovers the received data in a &[u8] . To print it out the received message it needs to be converted to a string using std::str::from_utf8.

2๏ธโƒฃ Subscribe to Topic: While we've defined the event behavior, we haven't subscribed to a topic yet. For that, we need to call the subscribe method on client that is of type EspMqttClient. Here's the code:

client.subscribe("testtopic/1", QoS::AtLeastOnce)?;

testtopic/1 is the default topic on HiveMQ. If you modify the topic there then you need to update it here.

When running the code, don't forget to connect the broker and then hit publish to see messages received by the ESP.

3๏ธโƒฃ Publish a Topic: To publish a topic, we need to call the publish method in client that is of type EspMqttClient. publish has 4 parameters; a &str topic parameter, a QoS type qos parameter, a bool retain parameter, and a &[u8] payload parameter. In the code we can create a count variable that is incremented and published under a topic mytopic/1 every second. Here's the code:

let mut count:u8 = 0;

loop {
  let msg = format!("Counter {}", count);
    // Keep waking up device to avoid watchdog reset
    client.publish("mytopic/1", QoS::AtLeastOnce, true, msg.as_bytes())?;
    count += 1;
    sleep(Duration::from_millis(1000));
}

๐Ÿ“ฑFull Application Code

Here is the full code for the implementation described in this post. You can additionally find the full project and others available on the apollolabs ESP32C3 git repo. Also, the Wokwi project can be accessed here.

use anyhow;
use embedded_svc::mqtt::client::Event;
use embedded_svc::mqtt::client::QoS;
use embedded_svc::wifi::{AuthMethod, ClientConfiguration, Configuration};
use embedded_svc::mqtt::client::Connection;
use esp_idf_hal::peripherals::Peripherals;
use esp_idf_svc::eventloop::EspSystemEventLoop;
use esp_idf_svc::mqtt::client::{EspMqttClient, MqttClientConfiguration};
use esp_idf_svc::nvs::EspDefaultNvsPartition;
use esp_idf_svc::wifi::{BlockingWifi, EspWifi};
use std::{thread::sleep, time::Duration};

fn main() -> anyhow::Result<()> {
    // It is necessary to call this function once. Otherwise some patches to the runtime
    // implemented by esp-idf-sys might not link properly. See https://github.com/esp-rs/esp-idf-template/issues/71
    esp_idf_sys::link_patches();

    let peripherals = Peripherals::take().unwrap();
    let sysloop = EspSystemEventLoop::take()?;
    let nvs = EspDefaultNvsPartition::take()?;

    let mut wifi = BlockingWifi::wrap(
        EspWifi::new(peripherals.modem, sysloop.clone(), Some(nvs))?,
        sysloop,
    )?;

    wifi.set_configuration(&Configuration::Client(ClientConfiguration {
        ssid: "Wokwi-GUEST".into(),
        bssid: None,
        auth_method: AuthMethod::None,
        password: "".into(),
        channel: None,
    }))?;

    // Start Wifi
    wifi.start()?;

    // Connect Wifi
    wifi.connect()?;

    // Wait until the network interface is up
    wifi.wait_netif_up()?;

    // Print Out Wifi Connection Configuration
    while !wifi.is_connected().unwrap() {
        // Get and print connection configuration
        let config = wifi.get_configuration().unwrap();
        println!("Waiting for station {:?}", config);
    }

    println!("Wifi Connected");

    // Set up handle for MQTT Config
    let mqtt_config = MqttClientConfiguration::default();

    // Create Client Instance and Define Behaviour on Event
    let mut client = EspMqttClient::new(
        "mqtt://broker.mqttdashboard.com",
        &mqtt_config,
        move |message_event| {
            match message_event.as_ref().unwrap() {
                Event::Connected(_) => println!("Connected"),
                Event::Subscribed(id) => println!("Subscribed to {} id", id),
                Event::Received(msg) => {
                    if msg.data() != [] {
                        println!("Recieved {}", std::str::from_utf8(msg.data()).unwrap())
                    }
                }
                _ => println!("{:?}", message_event.as_ref().unwrap()),
            };
        },
    )?;

    // Subscribe to MQTT Topic
    client.subscribe("testtopic/1", QoS::AtLeastOnce)?;

    let mut count:u8 = 0;

    loop {
      let msg = format!("Counter {}", count);
        // Keep waking up device to avoid watchdog reset
        client.publish("mytopic/1", QoS::AtLeastOnce,true,msg.as_bytes())?;
        count += 1;
        sleep(Duration::from_millis(1000));
    }
}

Conclusion

MQTT is a popular protocol in IoT applications due to its lightweight nature. As such, there is widespread support for MQTT implementations in many embedded devices. This post introduced how to set up MQTT publisher on ESP using Rust and the esp_idf_svc. Have any questions? Share your thoughts in the comments below ๐Ÿ‘‡.
